Curtain Wall System
At Abumet, we understand the importance of choice. Our high-performance curtain wall systems combine aesthetics, strength, and thermal efficiency to create sleek façades that meet demanding architectural and environmental requirements without compromise.
Schüco FW50/60+ & SG
Schüco FW50/60+ & SG
This impressive curtain wall system can be used to create structural glazing façades of both large and small dimensions and is perfect for sealing larger spaces in a building. The gaps between the curtain wall’s glass panes are incredibly thin (20mm), creating a completely clear glass effect. Readily combined with various other window and door systems, the Schüco FW50/60+ SG curtain wall system (structural) also features multiple benefits like smart thermal insulation. Let us know how you’d like yours customised.
Tested and certified by Schüco.
System Benefits
For more technical information, please download specification sheets (Schüco FW50 SG and Schüco FW60):
Unitized system
Unitized system
A unitized curtain wall system, also known as a panel system or modular system, consists of panels of glass, transoms and posts that are prefabricated and delivered to the construction site.
We can customise your unitized curtain walls in a number of ways to meet your requirements.
Technical specification
Framed options | Face width of 80mm or 65mm |
Glass size per field | 2000mm x 3000mm (with the standard size glass) |
Maximum glass load | 1000kg |
Glass thickness | 22-70mm |
Uf value | Max 0.81 W(m2K) |
For more technical information please download specification sheets (Schüco UDC 80):
Schüco FW50+ BF/FW60+BF and FR60 Curtain Wall System
Schüco FW50+ BF/FW60+BF and FR60 Curtain Wall System
Fire rated curtain walls are made to protect parts of or entire buildings from the damaging effects of heat and blazes. Similar to a stand curtain wall in terms of architectural design freedom, this fire rated curtain wall from Schüco is easily adapted to the dimensions of your space and features impressive thermal insulation as well as fire-resistance up to 60 minutes.
Tested and certified by Schüco.
System Benefits
Schüco FW50+ BF/FW60+BF & FR60 Curtain wall systemFire Protection System
Schüco FW50+BF/FW60+BF & FR60
Schüco FW50+BF/FW60+BF & FR60
Fire rated curtain walls are made to protect parts of or entire buildings from the damaging effects of heat and blazes. Similar to a standard curtain wall in terms of architectural design freedom, this fire rated curtain wall from Schüco is easily adapted to the dimensions of your space and features impressive thermal insulation as well as fire-resistance up to 60 minutes.
Tested and certified by Schüco.
System Benefits
For more technical information please download specification sheet (Schüco FW50 BF/ FW60 BF):
